Description
ATN Blaze Hunter 635 Thermal Monocular offers advanced thermal imaging technology suitable for night hunting and wildlife observation. With magnification options ranging from 2.5x to 20x, this monocular is equipped with a vanadium oxide uncooled focal plane detector available in 384x288 or 640x512 resolution, ensuring clear visibility even in low-light conditions. The large 0.41-inch OLED display features a resolution of 1440x1080, delivering superior image quality and six customizable color palettes for enhanced adaptability.
Powered by two quick-change rechargeable batteries, the Blaze Hunter provides up to 14 hours of continuous operation, making it reliable for extended outings. Select models include an integrated laser rangefinder, adding functionality for precise distance measurement. This thermal monocular is lightweight, portable, and designed for durability, making it an essential tool for serious outdoor enthusiasts.
Features – Key Benefits Bullets
- MULTIPLE MAGNIFICATION OPTIONS for versatility in observation, ranging from 2.5x to 20x.
- ensures clear thermal imaging with options for 384x288 or 640x512 resolutions.
- OLED DISPLAY with 1440x1080 resolution provides superior image clarity and detail.
- LONG BATTERY LIFE with two rechargeable batteries, offering a total runtime of 14 hours.
- INTEGRATED LASER RANGEFINDER in select models for accurate distance measurement during hunting.
- ADAPTABLE COLOR PALETTES with six options to tailor the display to various environments.
- LIGHTWEIGHT DESIGN at only 0.7 lbs, making it easy to carry on long excursions.
- DURABLE CONSTRUCTION ensures reliability in rugged outdoor conditions.
Technical Specifications
| SKU | TIMNBLH635-ATN |
|---|---|
| UPC | 658175124764 |
| MPN | TIMNBLH635 |
| Dimensions | 5.98" x 1.67" x 2.93" |
| Display | OLED 1440x1080 |
| Eye Relief | 15mm |
| Field of View | 12.4 x 10 |
| Monocular Magnification | 2.5x - 20x |
| Operating Time | 7 Hours Per Battery - 14 Hour Total Runtime |
| Sensor Resolution | 640x512 |
| Thermal Sensitivity | <18mK |
| Weight | 0.7 LBS |
| Item Condition | New |
| Product Type | Thermal |
What's in the Box?
- ATN Blaze Hunter 635 Thermal Monocular
- Two rechargeable batteries
- USB charging cable
- User manual
Customer Reviews
"The image quality is fantastic, even at night! Perfect for my hunting trips."
"Lightweight and easy to use. The battery life is impressive for long nights out."
"The integrated rangefinder is a game-changer. Highly recommend for serious hunters."
FAQ
How does the Blaze Hunter perform in low-light conditions? The Blaze Hunter excels in low-light environments due to its high-resolution thermal detector, providing clear images even in dark settings, making it ideal for night hunting.
What is the maintenance required for the ATN Blaze Hunter? Regularly clean the lenses with a soft cloth and store the device in a dry place. Ensure the batteries are charged and replaced as needed to maintain optimal performance.
How does the Blaze Hunter compare to other thermal monoculars? The Blaze Hunter offers superior resolution and features like an integrated rangefinder, setting it apart from many competitors. Its battery life also exceeds that of many models in its class.
Similar Models
Looking for more advanced thermal imaging options? Explore our complete lineup of ATN products, including the ATN OTS LT series for more compact designs and versatile features tailored to your outdoor needs.
Our Guarantees
FREE Fast Shipping Over $99
Enjoy complimentary expedited shipping on all orders over $99.
Secure Payments
Shop with confidence using our encrypted payment processing.
High Quality or Money Back
Not satisfied with your purchase? We'll refund your money, no questions asked.
Top-Notch Support
Our expert team is available to answer all your questions and provide assistance.
What Our Customers Say
Optics Knowledge Center
Understanding Rifle Scope Basics
Magnification
Magnification refers to how much larger an object appears through the scope compared to the naked eye. Fixed power scopes have one magnification setting, while variable power scopes offer a range (e.g., 3-9x).
Objective Lens
The objective lens is the front lens that gathers light. Larger objective lenses (measured in mm) gather more light, providing brighter images in low-light conditions but add weight and require higher mounting.
Reticle
The reticle (crosshair) is the aiming point inside the scope. Modern scopes offer various reticle designs, from simple duplex crosshairs to complex ballistic reticles with holdover points for different distances.
Adjustments
Rifle scopes have turrets for windage (horizontal) and elevation (vertical) adjustments. These are measured in MOA (minutes of angle) or MRAD (milliradians) and allow precise aiming adjustments.
Proper Scope Mounting Guide
Select the Right Rings & Base
Choose rings that match your scope's tube diameter (typically 1", 30mm, or 34mm). Select a base compatible with your rifle's receiver. For heavy-recoiling rifles, opt for stronger mounts.
Install the Base
Clean the receiver and base thoroughly. Apply a small amount of blue Loctite to the screws. Attach the base to the receiver and torque the screws to manufacturer specifications.
Attach the Rings
Attach the bottom halves of the rings to the base. Place the scope in the rings and loosely attach the top halves. Don't fully tighten yet.
Set Eye Relief & Level
Position the scope for proper eye relief (3-4 inches) in your normal shooting position. Ensure the reticle is level using a scope leveling tool. Once positioned correctly, tighten the rings evenly in a cross-pattern.
Scope Zeroing Tips
Start Close
Begin zeroing at a shorter distance (25-50 yards) to ensure you're on paper before moving to your desired zero distance (typically 100 yards).
Use a Stable Rest
Always zero your rifle from a stable shooting position using a bench rest, sandbags, or a shooting rest to eliminate as much human error as possible.
Fire Groups
Fire 3-shot groups before making adjustments. This provides a more accurate representation of where your rifle is shooting than single shots.
Make Deliberate Adjustments
Know your scope's adjustment values (typically 1/4 MOA per click). If your group is 2 inches low at 100 yards, you'll need to adjust up 8 clicks (for a 1/4 MOA scope).
Confirm Your Zero
After making adjustments, fire another group to confirm your zero. Repeat the process until your point of impact matches your point of aim.
Document Your Settings
Once zeroed, record your settings including distance, ammunition used, and environmental conditions for future reference.
Optics Maintenance & Care
Cleaning Lenses
- Start by blowing or brushing away loose particles
- Use a lens pen or microfiber cloth for fingerprints
- For stubborn dirt, use lens cleaning solution (never household cleaners)
- Clean with gentle circular motions from center outward
Protecting Your Optics
- Always use lens caps when not in use
- Store in a dry place with silica gel packets
- Avoid extreme temperature changes
- Use a quality scope cover in harsh conditions
Regular Maintenance
- Check and tighten mount screws periodically
- Inspect O-rings and seals for damage
- Verify zero after rough handling
- Clean the exterior with a damp cloth
What to Avoid
- Never use fingers to touch lenses
- Avoid paper products (tissues, paper towels) on lenses
- Don't use acetone, alcohol, or household cleaners
- Never disassemble your scope (voids warranty)
